The Teradek Clip is the world’s smallest and lightest H.264 transmitter developed specifically for unmanned aerial vehicles. Clip gives copter pilots a powerful HD video transmission solution for low latency monitoring on iOS devices or point to point broadcasts with Cube decoders over 2.4/5GHz WiFi. Clip has a micro HDMI, dual RP-SMA jacks for high gain antennas, and can transmit up to 300ft without a router.*

*Range can be greatly extended using routers and directional antennas.

Introducing Teradek Clip from Teradek on Vimeo.



Small Size, Low Power

Clip is about the size of a matchbox, requires little power, and weighs approximately 2 ounces. This means you never have to worry about sizable increases to your copter’s payload or inefficient power draw that may quickly deplete onboard batteries.



TDS Support

To ensure a robust low latency video transmission, Clip utilizes the custom TDS transport protocol, which allows you to fly in and out of range without having to restart the transmitter. RTSP is not supported.

Real-Time Monitoring on iOS Devices

Clip transmits directly to a single iOS device at less than 4 frames of latency, giving you a first person view of your UAV’s flight path in real time. A future update to the free TeraClip iOS app will allow you to view an optional HUD overlay for additional flight information.

This is Just the Beginning

Clip has a number of upcoming accessories that will allow you to monitor your footage on multiple devices and extend the range of your wireless transmission by hundreds of meters. Even better, Clip’s serial pass-through will allow you to transmit telemetry data back to a ground station and/or an iPad so you can review your flight data in real time.

Technical Specifications

    • Micro HDMI
    • Streaming Resolution Support:
    • 1080i 50/59.94/60
    • 1080p 23.98/24/25/30
    • 1080p 23.98/24/25
    • 720p 50/59.94/60
    • 576p
    • 480p
    • H.264 Compression: Main & Baseline
    • Video Bit Rate: 150kbps to 5mbps
    • Built-in scaler & deinterlacer
    • 2.4/5GHz a/b/g/n MIMO WiFi
    • Radio Output Power: 40mW
    • Encryption: AES128
    • Audio Compression: AAC-LC, MPEG Layer 2
    • Embedded Audio (2 channel) (micro HDMI)
    • Audio Bit Rate: 16kbps to 256kbps
    • 6-18V DC input barrel connector
    • Control Support: Serial pass-through
    • Nominal power consumption: 3.5W
    • Dimensions: 66 x 49 x 17mm
    • Weight: < 2 Oz
